Outdoor Loose Tube Amored With Steel Wires GYXTW 12 Core Fiber Optic Cable G652D
| | |
| | |
| | Fiber---G652D Sheath---PE or customized |
| | |
| | |
| | Within 20 days By sea, careful ship to your address! |
GYTXW 250μm's fibers are positioned in the central of a loose tube which is made of high modulus plastics and filled with water-resistant filling compound. The tube is wrapped with a layer of the plastic coated steel strip(PSP). Except the tube filling compound, PSP, water-blocking material and the PE sheath, it also has two steel wires in two sides to enhance the crush resistance and flexibility.
Feature:
Material of loose tube has good mechanical properties and temperature characteristics
• Material of loose tube has good hydrolysis resistance and high strength
• The tube is filled with special filler to provide critical protection for the fiber
• Good lateral pressure resistance and softness
• Double chrome plating plastic-coated steel tape (PSP) improves the moisture resistance of optical cables
• The two parallel steel wires provides enough tensile strength
• Small diameter, light weight, easy for laying
Applications
• Outdoor Duct, overhead
Optical Techology:
| Cable Count | Out sheath Diameter | Weight | Minimum allowable TensileStrength (N) | Minimum allowable Crush Load (N/100nm) | Minimum Bending Radius(MM) | Storage Temperature |
| (MM) | (kg) | Short term | Long term | Short term | Long term | Short term | Long term | (°C) |
| 12 | 8.3 | 78 | 1500 | 600 | 1000 | 300 | 20D | 10D | -40+60 |
| LCD Delivery | <10000m | <20000m | <50000m | >100000m |
| | 25days | 22days | 18days | 10days |
| | | | | |
FAQ:
1. Are you the real manufacturer?
Yes, we are factory in guangzhou china, welcome to visit us!
2. what is your minimum quantity?
1KM. We support new project of our customers, trial order is available
3.Can I get a sample?
Yes, we provide FREE sample and you just need to pay for express freight.
4.What about Payment?
L/C,T/T,Western Union and Paypal are acceptable.
5.Delivery time?
Generally 3-7 working days, also it is according to qty.
6.Can you supply customized products and logo?
Yes, we supply OEM&ODM service, pls feel free to contact.
Product Tags:
|
|
GYXTW 12 Core Fiber Optic Cable G652D Loose Tube Armored With Steel Wires Images
|
